Enerpac® RCH-603 Single Acting Spring Return Plunger Cylinder, 60 ton Capacity, 4.88 in Dia Bore, 3 in L Stroke, 9-3/4 in H Retract, 3.63 in Dia Rod, 10000 psi
Enerpac® RCH-603 Single Acting Spring Return Plunger Cylinder, 60 ton Capacity, 4.88 in Dia Bore, 3 in L Stroke, 9-3/4 in H Retract, 3.63 in Dia Rod, 10000 psi
-
BrandEnerpac®
-
UPC662005302932
-
Manufacturer Part NumberRCH-603
-
CountryUSA
-
Capacity60 ton
-
FinishBaked Enamel
-
Pressure Rating10000 psi
-
TypeSingle Acting Spring Return
-
Retract9-3/4 in H
-
Rod Diameter3.63 in
-
Mounting TypeBase
-
SeriesRCH
-
Housing MaterialSteel
-
Dimensions6-1/4 in OD
-
Stroke Length3 in
-
Bore Size4.88 in Dia
- Enerpac® hollow plunger cylinders provide versatility in testing, maintenance and tensioning applications
- The hollow plunger design allows for both pull and push forces
- Cylinders are nickel plated, floating center tube on models over 20 tons increases product life
- Baked enamel finish for increased corrosion resistance
- Collar threads for easy fixturing
-
UNSPSC27121602
-
Package Description1/PK
-
Standards/ApprovalsANSI B30.1
-
WarrantyLimited
-
Warranty Information
-
Instruction/Installation Manual
-
Catalog
