1309-K Tpr-ID Self Align Ball Bearing
TPR-ID SELF ALIGN BALL BEARINGS
Recently Viewed
TPR-ID SELF ALIGN BALL BEARINGS
• Bore Diameter (Shaft Size): 1-3/16 inches (or 30 mm variant depending on application specs)
• Housing Type: 2-Bolt Pillow Block (Light-Duty Base Mount)
• Locking Mechanism: Eccentric Locking Collar or Set Screw (varies by sub-manufacturer configuration)
• Bolt Hole Center-to-Center (J): 120 mm (4.724 in)
• Centerline Height (H): 42.9 mm (1.689 in)
• Overall Length (L/H2): 83 mm
1" STRAIGHT CORD-GRIP CONNECTOR - ELEL6933>
4" X 3" BLACK BUSHING-JPW4X3BB >
1" UNILET COVER NEOPRENE GASKETS-ELEL83G >
Inner Rings can be integrated with shell-type or various machined needle roller bearings to provide good roller support without worrying about premature shaft wear. We heat-treat and grind our Inner Rings to tight tolerances to create hard, tough raceways for applications where it is impossible to make shaft surfaces to a specific hardness or roughness attribute. They're an economical alternative to bushings because they don't require any additional machining. Wide Inner Rings are also available to accommodate shafts that move axially or seals that are adjacent to bearings. Inner Rings come in a broad range of shaft diameters and assembly elements include small chamfers or gentle taper relief options. These rings are designed to provide a durable surface for shell-type needle roller bearings with non-machined raceways in-type IRB series shaft diameters range from 5/16 to 2-1/2 in.
