Crosby® 1018856 215-3/8 Chain Shackle, 1 ton Load, 3/8 in, 7/16 in Dia Round Pin, Hot Dipped Galvanized
Crosby® 1018856 Chain Shackle, 1 ton Load, 3/8 in, 7/16 in Dia Round Pin, Hot Dipped Galvanized
-
BrandCrosby®
-
Manufacturer Part Number1018856
-
CountryUSA
-
Load Capacity1 ton
-
FinishHot Dipped Galvanized
-
SeriesG-215
-
Inner Length1.28 in
-
Inner Width0.66 in
-
Size3/8 in
-
Opening Size0.66 in
-
Body MaterialCarbon Steel
-
Overall Length2-5/16 in
-
Overall Width1.86 in
-
Eye Outer Size0.92 in
-
Pin Diameter7/16 in
-
Pin MaterialAlloy
-
Pin TypeRound
- Working load limit permanently shown on every shackle
- Shackles are quenched and tempered and can meet DNV impact requirements of 42 J at -20 deg C
- Look for the Red Pin® the mark of genuine Crosby® quality
-
UNSPSC24101641
-
Standards/ApprovalsABS/DNV/Lloyds/CE Certified|Federal Spec RR-C-271F|Type IVA|Grade A|Class 1
-
