Coffing® Hoists 12027W 12 EC Series Double Reeving Large Frame Electric Chain Hoist, 3 ton Load, 20 ft H Lifting, 2 hp Power Rating, 230/460 V AC
Coffing® EC hook and lug suspension models are high performance hoists engineered for heavy duty industrial service. Designed for safety, the EC incorporates mechanical load brake, motor brake and overload clutch as standard.
-
BrandCoffing® Hoists
-
Manufacturer Part Number12027W
-
CountryUSA
-
Load Capacity3 ton
-
Power Rating2 hp
-
ColorWhite Enamel
-
TypeDouble Reeving Large Frame
-
Voltage Rating230/460 V AC
-
Control Type1-Speed
-
SeriesEC Series
-
Dimensions31-3/16 in L x 14-13/16 in W x 10-7/8 in H
-
Brake TypeMultiple Disc Motor/Mechanical Load
-
Lifting Height20 ft
- Standard push button drop is 4 ft less than lift
- Large frame design features load bearing housings of ductile iron construction for maximum strength, non-load bearing housings of cast aluminum alloy for minimum weight
- Engineered and designed for use with higher torque 2 and 3 hp three phase motors
- Durable construction
-
UNSPSC24101602
-
Standards/ApprovalsASME/ANSI B30.16|CSA Certified
-
Specification Sheet
