Power Team® RSS202 Heavy Duty Shorty Welded Hydraulic Cylinder, 20 ton, 2-3/8 in Bore, 1-3/4 in L Stroke, 3-3/4 in H Retract, 2-5/32 in Dia Rod, 9029 psi
Power Team® RSS202 Heavy Duty Shorty Welded Hydraulic Cylinder, 20 ton, 2-3/8 in Bore, 1-3/4 in L Stroke, 3-3/4 in H Retract, 2-5/32 in Dia Rod, 9029 psi
-
BrandPower Team®
-
Manufacturer Part NumberRSS202
-
CountryUSA
-
Capacity20 ton
-
Port Size5/8 in
-
Pressure Rating9029 psi
-
TypeHeavy Duty Shorty Welded
-
Retract3-3/4 in H
-
Rod Diameter2-5/32 in
-
SeriesRSS
-
Dimensions3-9/16 in OD
-
Stroke Length1-3/4 in
-
Bore Size2-3/8 in
- Power-tech nitro-carburization surface treatment inhibits corrosion and provides exceptional durability for the rod and piston
- Heavy-duty return spring (except for double-acting models) provides fast piston return and low collapsed height
- Coupler on 10-50 ton models is angled upward 5 for added clearance
- Grooved piston top keeps load from sliding
- Cylinders can be Dead-ended at full capacity
- Removable carrying handles on 100 and 250 ton models
-
UNSPSC27121602
-
Standards/ApprovalsASME B30.1|CE Certified
-
Instruction/Installation Manual
-
Catalog
