Enerpac® RCH1003 Hollow Plunger Single Acting Spring Return Hydraulic Cylinder, 103.1 ton Advance Capacity, 6-1/2 in Bore, 3 in L Stroke, 10 in Retract, 4.97 in Dia Rod, 10000 psi Pressure
Enerpac® RCH1003 Hollow Plunger Single Acting Spring Return Hydraulic Cylinder, 103.1 ton Advance Capacity, 6-1/2 in Bore, 3 in L Stroke, 10 in Retract, 4.97 in Dia Rod, 10000 psi Pressure
-
BrandEnerpac®
-
UPC662005303090
-
Manufacturer Part NumberRCH1003
-
CountryUSA
-
Capacity103.1 ton Advance
-
FinishBaked Enamel
-
Port Size3/8-18 NPTF
-
Pressure Rating10000 psi
-
TypeHollow Plunger Single Acting Spring Return
-
Retract10 in
-
Rod Diameter4.97 in
-
Mounting TypeBase
-
SeriesRCH Series
-
Housing MaterialSteel
-
Dimensions8.38 in OD x 13 in H
-
Stroke Length3 in
-
Bore Size6-1/2 in
- Hollow plunger design allows for both pull and push forces
- Nickel plated, floating center tube on models over 20 ton increases product life
- Baked enamel finish for increased corrosion resistance
- Collar threads for easy fixturing
-
UNSPSC27121602
-
Standards/ApprovalsEAR99|ETC Certified
-
WarrantyLimited
-
Instruction/Installation Manual
-
Service Manual
-
Line Drawing
-
Specification Sheet
-
Warranty Information
