Power Team® RSS101 Shorty Single Acting Spring Return Hydraulic Cylinder, 10 ton Capacity, 1-11/16 in Dia Bore, 1-1/2 in L Stroke, 3-1/2 in H Retract, 1-1/2 in Dia Rod, 8943 psi

Name: Power Team® RSS101 Shorty Single Acting Spring Return Hydraulic Cylinder, 10 ton Capacity, 1-11/16 in Dia Bore, 1-1/2 in L Stroke, 3-1/2 in H Retract, 1-1/2 in Dia Rod, 8943 psi
Brand: Hydraulic Technologies
SKU: PTDRSS101
Price: 941.64 USD
Availability: InStock

0 Ratings

$941.64

SKU: PTDRSS101

Power Team® RSS101 Shorty Single Acting Spring Return Hydraulic Cylinder, 10 ton Capacity, 1-11/16 in Dia Bore, 1-1/2 in L Stroke, 3-1/2 in H Retract, 1-1/2 in Dia Rod, 8943 psi

In Stock

HCI of Jackson: 0

HCI of Dyersburg: 0

HCI of Humboldt: 0

HCI of Union City: 0

HCI of Gallatin: 0

Back to: Hydraulic Welded Cylinders

Main specs

Brand

Power Team®
UPC

662536003551
Manufacturer Part Number

RSS101
Country

USA|Canada

Specification

Capacity

10 ton
Pressure Rating

8943 psi
Type

Shorty Single Acting Spring Return
Retract

3-1/2 in H
Rod Diameter

1-1/2 in
Series

RSS
Housing Material

Steel
Dimensions

2-3/4 in OD
Stroke Length

1-1/2 in
Bore Size

1-11/16 in Dia

Features

Power-tech nitro-carburization surface treatment inhibits corrosion and provides exceptional durability for the rod and piston
Heavy-duty return spring (except for double-acting models) provides fast piston return and low collapsed height
Coupler on 10-50 ton models is angled upward 5 for added clearance
Grooved piston top keeps load from sliding
Cylinders can be Dead-ended at full capacity
Removable carrying handles on 100 and 250 ton models

Additional Information

UNSPSC

27121602
Standards/Approvals

ASME B30.1

Attachments

Instruction/Installation Manual

Click here
Catalog

Click here
