Bussmann AGC-4 Small Dimension Fast Acting Fuse, 4 A, 250 VAC, 200 A/10 kA Interrupt, Cylindrical Body
Bussmann AGC-4 Small Dimension Fast Acting Fuse, 4 A, 250 VAC, 200 A/10 kA Interrupt, Cylindrical Body
-
BrandBussmann
-
UPC051712703871
-
Manufacturer Part NumberAGC-4
-
CountryUSA
-
Terminal TypeFerrule
-
MaterialGlass
-
Rejection/Non-RejectionNon-Rejection
-
Response Time60 min, 120 s
-
TypeSmall Dimension
-
Mounting TypeClip/Holder
-
Voltage Rating250 V AC
-
Amperage Rating4 A
-
SeriesAGC
-
Indicating/Non-IndicatingNon-Indicating
-
Interrupt Rating200 A/10 kA
-
Body Size1/4 in Dia x 1-1/4 in L
-
Body TypeCylindrical
-
ElementSingle
- 200 A at 250 VAC, 10 kA at 125 VAC interrupt rating
- 60 min maximum at 135%, 120 s maximum at 200%
-
Alternative Part Number7637095
-
UNSPSC39121607
-
IDEA Index ID7637095
-
Package DescriptionEACH
-
Standards/ApprovalsUL 248-14|JDYX E19180|CSA Class 1422-01 53787|CSA Certified
-
Specification Sheet
-
Catalog
