Littelfuse® POWR-GARD® CNN500 Fast Acting Fuse, 500 A, 48 V DC, 2500 A Interrupt
CNN_E fuses are rated for applications up to 80 VDC. As fork lift trucks voltages increase, circuit protection needs to be rated higher than the standard CNN products to handle the increased voltage. The CNN_E is considered very fast acting for quicker reaction time.
-
BrandLittelfuse®
-
UPC079458009101
-
Manufacturer Part NumberCNN500
-
CountryUSA
-
Terminal TypeBlade
-
Mounting TypeStud
-
Voltage Rating48 V DC
-
Amperage Rating500 A
-
SeriesCNN
-
Indicating/Non-IndicatingIndicating
-
Interrupt Rating2500 A
-
Body Size3.18 in L
- Compact size saves space
- Window shows fuse status
- 2500 A at 48 VDC interrupt rating
-
Alternative Part Number0CNN500.V|8555907
-
UNSPSC39121606
-
IDEA Index ID8555907
-
Package DescriptionEACH
-
Standards/ApprovalsRoHS Compliant
-
Specification Sheet
-
Owners/User Manual
-
Full Engineering Drawing
-
Technical Bulletin
