Littelfuse® POWR-GARD® LFJ600303C Non-Indicating Fuse Block, 600 V AC, 30 A, Class: J, 3 Poles
Littelfuse® POWR-GARD® LFJ600303C Non-Indicating Fuse Block, 600 VAC, 30 A, Class: J, 3 Poles
-
BrandLittelfuse®
-
UPC079458808810
-
Manufacturer Part NumberLFJ600303C
-
CountryUSA|Canada
-
Temperature Rating125 deg C
-
ClassJ
-
ColorBlack
-
TypeNon-Indicating
-
Connection TypeBox Lug
-
Mounting TypeDIN Rail
-
Voltage Rating600 V AC
-
Amperage Rating30 A
-
SeriesLFJ
-
Number of Poles3
-
Dimensions49.5 mm L x 82.5 mm W x 94.1 mm H
- DIN rail releasable for all non-knife blade style fuses
- Only one hand is required to release from DIN rail (lock open lock closed)
- Phenolic blocks have side barriers for isolation
- Reinforcing springs are optional on 30 A and 60 A blocks
- Universal mounting holes make for easy replacement
- Space saving design, up to 45% smaller than existing blocks
- Lead-free
- Copper solid/stranded wire
- 2.8 N-m torque rating
-
UNSPSC39121600
-
Package DescriptionEACH
-
Standards/ApprovalsUL/cUL Listed|CSA Certified|RoHS Compliant
-
Specification Sheet
-
Owners/User Manual
-
Full Engineering Drawing
-
Technical Bulletin
