Littelfuse® POWR-GARD® LFJ60200-3C Fuse Block, 600 V AC, 200 A, Class: J, 6 AWG to 250 kcmil Wire, 3 Poles
The Littelfuse® 600 VAC class J blocks offer generous space savings and enhanced value Over previous generations, such as indication, snap-to-release DIN rail mounting and universal mounting holes.
-
BrandLittelfuse®
-
UPC079458181944
-
Manufacturer Part NumberLFJ60200-3C
-
CountryUSA|Canada
-
Temperature Rating130 deg C
-
MaterialThermoplastic
-
ClassJ
-
Fuse Diameter1-1/2 in
-
Fuse Length5.752 in
-
Connection TypeBox Lug
-
Mounting TypeDIN Rail
-
Voltage Rating600 V AC
-
Amperage Rating200 A
-
SeriesLFJ
-
Wire Size6 AWG to 250 kcmil
-
Number of Poles3
-
Dimensions6.13 in L x 8 in W x 2.85 in H
-
Suitable For Use WithJTD/JTD_ID Series Time Delay, JLS Series Fast Acting Fuse
- Space saving design upto 45% smaller than existing blocks
- Universal mounting holes for easy replacement
- Only 1-hand is required to release from DIN rail (lock open lock closed)
- Spring reinforced fuse clips are standard on 100 A and larger blocks, reinforcing springs are optional on 30 and 60 A blocks
- <0.6 mA at 600 VAC leakage current
- Lead-free
- Phenolic blocks have side barriers for isolation
- Indication offered on all versions except 200 to 600 A
- DIN rail releasable for all non-knife blade style fuses
- Covers available for 100 a and lower to enhance safety
| Competitor Name | Cross-Reference Number |
|---|---|
| Grainger | 6MUN3 |
-
Alternative Part Number11023088
-
UNSPSC39121629
-
IDEA Index ID11023088
-
Package DescriptionEACH
-
Standards/ApprovalsUL Listed|CSA Certified|UL 94 V-0 Flammability Rating|PROP65: This product can expose you to chemicals including nickel, which is known to the State of California to cause cancer.
-
Specification Sheet
-
Owners/User Manual
-
Technical Bulletin
