Loctite® 135393 290™ Low Viscosity Medium High Strength Wicking Grade Threadlocker, 250 mL Bottle, Liquid Form, Green
LOCTITE® 290 is a liquid medium/high-strength thread locker designed for the locking and sealing of threaded fasteners. Because of its low viscosity and capillary action, the product wicks between engaged threads and eliminates the need for disassembly prior to application. The product cures when confined in the absence of air between close-fitting metal surfaces and prevents loosening and leakage due to shock and vibration. The product can also fill porosities in welds, castings and powdered metal parts.
-
BrandLoctite®
-
UPC079340290419
-
Manufacturer Part Number135393
-
CountryUSA
-
Temperature Rating-65 to 300 deg F
-
Flash Point>199.94 deg F
-
FormLiquid
-
ColorGreen
-
TypeLow Viscosity Medium High Strength Wicking Grade
-
Viscosity Rating25 to 55 cPs
-
Container Size250 mL
-
Container TypeBottle
-
Applicable MaterialsMetal
-
Series290™
-
Curing Time24 hr
-
Setting Time20 min
-
Shear Strength780 psi
-
Specific Gravity1.07
-
Drying Time20 min
- Penetrates threads by capillary action
- Seals welds and porous metal parts
- Anaerobic curing method slightly soluble in water
- Removable with heat and hand tools
| Competitor Name | Cross-Reference Number |
|---|---|
| Grainger | 4KL55 |
-
Alternative Part Number29041
-
UNSPSC31201701
-
Package Description1/PK
-
Standards/ApprovalsASTM D-5363|CFIA Certified|MIL-S-46163A|NSF/ANSI 61|OEM Approved|OSHA 29 CFR 1910.1200
-
