Leviton® Wetguard® 29W09 3-Phase Non-Grounding Watertight Cable Mount Locking Connector, 120/208 V AC, 30 A, 4 Poles, 4 Wires, Yellow
Leviton® Wetguard® 29W09 3-Phase Non-Grounding Watertight Cable Mount Locking Connector, 120/208 VAC, 30 A, 4 Poles, 4 Wires, Yellow
-
BrandLeviton®
-
UPC078477968871
-
Manufacturer Part Number29W09
-
CountryUSA
-
Temperature Rating-40 to 60 deg C
-
Terminal TypeScrew
-
MaterialTPV
-
ColorYellow
-
Type3-Phase Non-Grounding Watertight Cable Mount
-
GradeIndustrial
-
Voltage Rating120/208 V AC
-
Cord Diameter5/8 to 1-1/8 in
-
Amperage Rating30 A
-
Number of Poles4
-
Dimensions2.75 in Dia x 5.52 in L
-
Number of Wires4
-
Alternative Part Number7356734
-
UNSPSC39121402
-
IDEA Index ID7356734
-
Package DescriptionEACH
-
Standards/ApprovalsANSI C73|CSA C22.2 No.42 File No. LR406|NOM 057|NEMA WD1/WD6|UL 498|UL94 V-2 Flammability Rating
-
Catalog
-
Specification Sheet
-
Owners/User Manual
