B&K® 116-502 ProLine™ Ball Valve, 3/8 in Nominal, Flare End Style, Brass Body
B&K® 116-502 ProLine™ Ball Valve, 3/8 in Nominal, Flare End Style, Brass Body
-
BrandB&K®
-
UPC032888165021
-
Manufacturer Part Number116-502
-
CountryUSA
-
Temperature Rating-20 to 300 deg F
-
Pressure Rating200 psi
-
MediaGas
-
Actuator TypeLever Operated
-
Nominal Size3/8 in
-
SeriesProLine™
-
Body MaterialBrass
-
End StyleFlare
- Quarter turn lever handle for positive on-off operation
- Coated aluminum handle for corrosion and solvent resistance
- Multi-directional flow
- One-piece body for leak resistance and long valve life
| Cross-Reference Number |
|---|
| 433764 |
-
UNSPSC40141607
-
Standards/ApprovalsANSI B16.44/Z21.15|ASME B16.44|CSA Certified|SAE J513
