Lift-All® Webmaster® 1600 EE1804DFX6 Flat Eye and Type 3 Eye Web Sling, 6 ft L x 4 in W, 6400 lb, Polyester
Webmaster® 1600 is the traditional standard of heavy duty slings. The red core yarn warning system aids in the inspection process and the Yellow treatment extends sling life while also resisting abrasion.
-
BrandLift-All®
-
UPC697886265113
-
Manufacturer Part NumberEE1804DFX6
-
CountryUSA
-
Temperature Range-60 to 200 deg F
-
MaterialPolyester
-
Choker Hitch Capacity5000 lb
-
CoatingLatex
-
ColorYellow
-
TypeFlat Eye and Type 3 Eye
-
Vertical Hitch Capacity6400 lb
-
Web GradeHeavy Duty
-
Width4 in
-
Number of Plys1
-
Basket Hitch Capacity12800 lb
-
Length6 ft
-
Eye Length12 in
- Traditional standard in web slings
- TUFF-TAG™ for permanent identification
- Web slings are light weight, flexible and have wide bearing surfaces to help protect the load
- Their stretch characteristics help to avoid shock loading problems
- Polyester web stretches less, promotes load control
- Resists UV sunlight, grease and most acids
- Red core yarn warning system aids in the inspection process
- Always protect synthetic slings from being cut by corners and edges
- See Sling Protection section in the Lift-All catalog
- Polyester webbing stretches less for better control and the yellow treatment is resistant to abrasion
| Competitor Name | Competitor Part Number |
|---|---|
| Grainger | 38U382 |
-
UNSPSC24101611
-
Package DescriptionEACH
-
Standards/ApprovalsASME B30.9|OSHA 29 CFR 1910.184|WSTDA WS-1
-
WarrantyLimited Liability Warranty
-
Technical Bulletin
-
Catalog
-
Instruction/Installation Manual
