Armstrong® 26-567 Box End Wrench, 1/2 x 9/16 in Wrench, 12 Points, 15 deg Offset, 5-1/2 in OAL, High Alloy Steel, Full Polished, ASME B107.6-1994
Armstrong® 26-567 Box End Wrench, 1/2 x 9/16 in Wrench, 12 Points, 15 deg Offset, 5-1/2 in OAL, High Alloy Steel, Full Polished, ASME B107.6-1994
-
BrandArmstrong®
-
UPC781412265675
-
Manufacturer Part Number26-567
-
CountryUSA
-
Finish/CoatingFull Polished
-
MaterialHigh Alloy Steel
-
Measurement SystemImperial
-
Handle TypeShort
-
Wrench Opening1/2 x 9/16 in
-
Wrench TypeOffset
-
Number of Points12
-
Specifications MetASME B107.6-1994
-
Offset Angle15 deg
-
Overall Length5-1/2 in
-
Box End Thickness0.312 x 0.343 in
-
Box End Width0.75 x 0.812 in
- Both box ends incorporate a radius corner design that engages the flats of the fastener, not the corners, providing up to 15 to 20% more torque while reducing fastener rounding, enhancing the turning of worn fasteners
- Two different size openings on opposite ends provides broader coverage than a combination wrench, less wrenches to carry
- Box ends are offset 15 deg for clearing obstructions and knuckle clearance on flat surfaces
- Manufactured from high alloy steel using the most up-to-date manufacturing process and heat treat for greater strength and durability
| Competitor Name | Cross-Reference Number |
|---|---|
| MSC | 86999141 |
-
UNSPSC27111705
-
Standards/ApprovalsUS Federal Specification GGG-W-636E
