Edison TJS80 Very Fast Acting Fuse, 80 A, 600 V AC, 200 kA Interrupt, T Class
Edison's Class T current-limiting, fast-acting fuses. Provides 10X better current limitation to help prevent equipment damage caused by short-circuit events. 200 kA Interrupting rating complies with NEC Section 110.9 for todayās large capacity systems. Small, space-saving fuses provide a high degree of current limitation on short-circuits for excellent component protection.
-
BrandEdison
-
UPC782634807230
-
Manufacturer Part NumberTJS80
-
CountryUSA
-
ClassT
-
Voltage Rating600 V AC
-
Amperage Rating80 A
-
SeriesTJS
-
Indicating/Non-IndicatingNon-Indicating
-
Interrupt Rating200 kA
-
Body Size2.95 in L
- No intentional time delay, opens quickly on overload
- Extremely current-limiting silver link construction; provides superior short-circuit component protection
- Use to protect lower interrupting rating circuit breakers when series rated with Class T fuses
- For motor protection, size at 300% FLA which provides short circuit protection only
-
Alternative Part Number8431481
-
UNSPSC39121626
-
IDEA Index ID8431481
-
Package DescriptionEACH
-
Standards/ApprovalsCE Certified|C22.2 No 248.15|Class 1422-02|CSA Certified|Guide JDDZ|Std. 248-15|UL Listed
-
Specification Sheet
