EATON CH215GFT Type CH Self-Test Ground Fault Circuit Breaker, 120/240 V AC, 15 A, 10 kA Interrupt, 2 Poles, Thermal Magnetic Trip
Eaton's residential CH circuit breakers provide premium overload protection. The Type CH circuit breakers trip to the OFF position, eliminating nuisance callbacks. The CHF family also includes a trip flag to differentiate between a trip and the breaker being turned off. The thermal-magnetic trip curve avoids nuisance tripping on mild overloads while reacting almost instantaneously to severe short-circuit conditions. Multiple breakers have an internal common trip connection to operate all poles simultaneously. Handles are marked with ON-OFF indication and ampere rating of the breaker.
-
BrandEATON
-
UPC786676025614
-
Manufacturer Part NumberCH215GFT
-
CountryUSA
-
Temperature Rating60 to 75 deg C
-
Trip Range5 mA
-
Trip TypeThermal Magnetic
-
TypeType CH Self-Test
-
Connection TypePlug-On
-
Actuator TypeHandle
-
Voltage Rating120/240 V AC
-
Amperage Rating15 A
-
Wire Size14 to 4 AWG
-
Number of Poles2
-
Dimensions4-1/2 in L x 2-3/4 in W x 2 in H
-
Interrupt Rating10 kA
-
Enclosure TypeNEMA 1/3R
- The panel neutral conductor connects to the neutral bar, even though the neutral is not included in a 240 VAC load circuit
- This connection is necessary to supply a 120 VAC power source to the ground fault sensing circuit
-
Alternative Part Number13204494
-
UNSPSC39121603
-
IDEA Index ID13204494
-
Package DescriptionEACH
-
Standards/ApprovalsUL 489
-
Specification Sheet
-
Owners/User Manual
