IDC Select® IDC H50BTL16 Taper-Lock® Type B Single Strand Roller Chain Sprocket, 1-5/8 in Dia Bore, 3.517 in OD, 50 Chain, 16 Teeth, 5/8 in Pitch, C1045 Steel
IDC Select® offers a wide range of high quality roller chain sprockets produced in ISO certified facilities to ANSI standards. Plain bore, finished bore, taper and QD® bushing designs are available. All IDC Select® sprockets come with hardened teeth and black oxide finish for long lasting service life. The finished bore design comes complete with a keyway on the centerline of the sprocket tooth and two setscrews, one over the keyway and one at 90 deg.
-
BrandIDC Select®
-
UPC887412055398
-
Manufacturer Part NumberIDC H50BTL16
-
CountryUSA
-
Bushing Type1610 Taper Lock
-
Pitch5/8 in
-
Pitch Diameter3.204 in
-
FinishBlack Oxide
-
MaterialC1045 Steel
-
Chain Size50
-
TypeTaper-Lock® Type B
-
Hub Diameter2-25/32 in
-
Number of Teeth16
-
Outside Diameter3.517 in
-
Length Through Bore1 in
-
Bore Diameter1-5/8 in
- Hardened teeth for longer life
- Clean and compact taper bushed design
-
UNSPSC31171901
-
Package Description1/PK
-
Standards/ApprovalsANSI Specified
-
