Martin 50JA13 QD Bushed Type B Single Pitch Roller Chain Sprocket, 2.911 in OD, #50 Chain, 13 Teeth, 5/8 in Pitch, Steel
QD (quick detachable)is a sprocket where a tapered bushing is bolted into the taper bore that is machined in the sprocket. When installed this bushing is compressed onto the shaft providing a tight grip.
-
BrandMartin
-
UPC697950010090
-
Manufacturer Part Number50JA13
-
CountryUSA|Canada
-
Bushing TypeType JA QDĀ®
-
Pitch5/8 in
-
Pitch Diameter2.612 in
-
MaterialSteel
-
Chain Size#50
-
TypeQD Bushed Type B
-
Hub Diameter2 in
-
Number of Teeth13
-
Outside Diameter2.911 in
-
Length Through Bore5/8 in
- Manufactured of high carbon steel
- Precise machining and processes ensure consistent finish and high quality
- Chain rows are parallel and precisely spaced to increase longevity of sprocket and chain
-
UNSPSC31171901
-
Package Description1/PK
-
Standards/ApprovalsPROP65: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. For more information: www.P65Warnings.ca.gov
-
