Gates® Power Transmission Hi-Power® II C78 Banded Classical Heavy Duty V-Belt, C Section, 7/8 in W Top, 82 in L Outside, 17/32 in THK, EPDM
The wrapped classical section Hi-Power™ V-belt has a long reputation for reliability on agricultural and industrial applications. The arched top of the Hi-Power belt provides superior strength to prevent "dishing" and distortion of the tensile section. The cords are properly aligned, each of them carrying its full share of the load.
-
BrandGates® Power Transmission
-
UPC72053210477
-
Manufacturer Part NumberC78
-
CountryUSA|Canada
-
Thickness17/32 in
-
MaterialEPDM
-
Top Width7/8 in
-
Reinforced MaterialFlex-Bonded Polyester
-
TypeBanded Classical Heavy Duty
-
Minimum Pulley Diameter7.958 in
-
Section SizeC
-
Series9004
-
Number of Ribs1
-
Outside Length82 in
- Flex-bonded cords are strongly bonded to the body of the belt resulting in equal load distribution and the absorption of bending stress without cord deterioration
- The Flex-Weave® cover is constructed for longer cover life, providing extended protection to the core of the belt from oil, dirt and heat
- Gates® curves provide proper cord support and full contact with the sheave groove for uniform loading, uniform wear and increased belt life
- Featuring a composite, multi-purpose construction, these belts resist oil and heat, ozone, sunlight, weather and aging
-
Alternative Part Number90042078
-
UNSPSC26111801
-
Package DescriptionEACH
-
Standards/ApprovalsARPM/RMA IP-3-2/IP-3-3
-
Instruction/Installation Manual
-
Specification Sheet
-
Catalog
