FYH® UCPX05 16 UCP Medium Duty Pillow Block Unit, 1 in Dia Bore, 4-11/16 in L Bolt Center-to-Center, 1-3/4 in Base to Bore Centerline, 6-1/4 in OAL 3-3/8 in OAH
FYH® UCPX05 16 UCP Medium Duty Pillow Block Unit, 1 in Dia Bore, 4-11/16 in L Bolt Center-to-Center, 1-3/4 in Base to Bore Centerline, 6-1/4 in OAL 3-3/8 in OAH
-
BrandFYH®
-
Manufacturer Part NumberUCPX05 16
-
CountryUSA
-
Load Capacity19.5 kN Dynamic/11.3 kN Static
-
Locking DeviceSet Screw
-
MaterialCast Iron
-
TypeMedium Duty
-
SeriesUCP
-
Base Width2 in
-
Base to Bore Centerline1-3/4 in
-
Bolt Center-to-Center Length4-11/16 in
-
Bore Diameter1 in
-
Bore TypeCylindrical
-
Overall Height3-3/8 in
-
Overall Length6-1/4 in
-
Overall Width2 in
