Dodge® 421255 215 Type Unisphere II Spherical Roller Insert Bearing With Seal, 3 in Dia Bore, 5.1181 in OD, 2 Rows, 1.27 in Outer Ring/2.45 in Inner Ring W, 41500 lb Dynamic/53000 lb Static Load
Dodge® 421255 215 Type Unisphere II Spherical Roller Insert Bearing With Seal, 3 in Dia Bore, 5.1181 in OD, 2 Rows, 1.27 in Outer Ring/2.45 in Inner Ring W, 41500 lb Dynamic/53000 lb Static Load
-
BrandDodge®
-
UPC782475884537
-
Manufacturer Part Number421255
-
CountryUSA
-
Load Capacity41500 lb Dynamic/53000 lb Static
-
Temperature Rating-100 to 400 deg F
-
FinishUncoated
-
Maximum Speed1700 rpm
-
TypeType Unisphere II
-
Seal MaterialSteel
-
Width1.27 in Outer Ring/2.45 in Inner Ring
-
Series215
-
Number of Rows2
-
Bearing MaterialCast Iron
-
Outside Diameter5.1181 in
-
Bore Diameter3 in
- High capacity double row spherical bearings
- Same rolling elements and installation ready features as the S-2000 bearing
- Ductile iron pillow block housing with 65000 psi tensile strength is 92% the strength of steel
- Dodge® R seal provides contacting lip protection, crimped to the outer race and maintains sealing effectiveness at maximum misalignment
- Springlok™ collar mount with 65 setscrew spacing for optimum clamping force
- Mobilgrease XHP222 grease
- Double sealed
| Competitor Name | Cross-Reference Number |
|---|---|
| Applied Industrial Technologies | 101857519 |
-
Alternative Part NumberINS-UN2-300R
-
UNSPSC31171536
-
Package Description1/PK
-
Standards/ApprovalsABMA|AGMA|CMA|MPTA|PMBSA|PTDA Standards|UL Listed
-
