Link-Belt® 10437944 B22400 Expansion Flanged Block Spherical Roller Bearing, 1-1/2 in Dia Bore, 5 in Dia Bolt Circle, 3-Bolt Round Flange Mount, 5-7/8 in OAL/Dia
Self aligning double row spherical roller bearings are designed to distribute the load over the symmetrical rollers, assuring positive tracking and smooth operation. The large roller complement provides high capacity for radial or combined radial-thrust loads. Osculation clearance at the ends of the rollers compensates for shock loads and prevents destructive edge loading. These precision bearings with double contoured retainer pockets are designed to meet a broad range of application requirements.
-
BrandLink-Belt®
-
UPC662327030155
-
Manufacturer Part Number10437944
-
CountryUSA|Canada
-
Load Capacity17800 lb Dynamic/20900 lb Static
-
Locking DeviceSingle Set Screw Collar
-
Temperature Rating-40 to 400 deg F
-
FinishPowder Coated
-
Flange Mounting Type3-Bolt Round
-
Maximum Speed3600 rpm
-
TypeExpansion
-
SeriesB22400
-
Bolt Circle Diameter5 in
-
Bore Diameter1-1/2 in
-
Overall Depth2-29/32 in
-
Overall Height6-1/4 in
-
Overall Length/Diameter5-7/8 in
- Spherical roller bearing allows for +/- 2 deg of misalignment to accommodate variations between shaft and support structure as well as shaft deflection during operation
- Double contoured retainer pockets
- Cast iron housing
- Factory set clearance and lubrication
- Extended inner ring, separable outer rings
- Type H floating labyrinth clearance seals have multiple self-centering rings held securely in a steel carrier
-
Alternative Part NumberFEB22424H
-
UNSPSC31171501
-
Standards/ApprovalsANSI/ABMA STD 11
-
Warranty1 Year
-
Package DescriptionEACH
-
