Leviton® 5501-LHI Grounding Illuminated-OFF AC Quiet Toggle Switch, 120 V AC, 15 A, 1/2 hp Power Rating
Leviton® commercial specification grade switches are designed to offer outstanding reliability and top performance in commercial settings. Ideal applications include municipal facilities, government buildings, malls, department stores, hospital and health care facilities, office buildings, schools, colleges, universities, houses of worship and cultural institutions. Leviton® offers a large selection of 15 and 20 A commercial switches, available in a wide variety of colors, wiring options and other features.
-
BrandLeviton®
-
UPC078477789889
-
Manufacturer Part Number5501-LHI
-
CountryUSA
-
Terminal TypeSide Wire
-
MaterialThermoplastic
-
Power Rating1/2 hp
-
ColorIvory
-
TypeGrounding Illuminated-OFF
-
MountingSurface
-
Contact ConfigurationSP
-
ActuatorToggle
-
Voltage Rating120 V AC
-
Amperage Rating15 A
-
Number of Poles1
-
Dimensions46 in H x 1.31 in W x 1.49 in D
-
EnclosureNEMA WD-1/WD-6
-
Environmental Conditions-40 to 120 deg C Operating Temperature
- Quiet, reliable mechanical action
- Large head triple drive combination screws (standard, Phillips and Robertson) for fast wiring installation
- Accepts no 14 to 12 AWG copper or copper clad wire
- Large switch contacts for maximum conductivity
- 1/2 hp at 120 VAC power rating
| Competitor Name | Cross-Reference Number |
|---|---|
| Grainger | 25KW26 |
| 517003 |
-
Alternative Part Number12130310
-
UNSPSC39122211
-
IDEA Index ID12130310
-
Package DescriptionEACH
-
Standards/ApprovalsANSI C73|CSA C22.2 No. 111 File No. 152105|NOM 057|Federal Specification WS896E File No. E7458|UL 20|UL94 V-2 Flammability Rating
-
Instruction/Installation Manual
-
Owners/User Manual
