ILSCO® ClearChoice® IK-500 Type IK Split Bolt Connector, 250 to 500 kcmil, 8 AWG Compact/Compressed/Concentric/Solid Copper Conductor, 1-5/8 x 3 in, Copper Alloy

0 Ratings
$85.88
In Stock
SKU: ILSIK500
GTIN (EAN,ISBN): 00783669470222
noimage_new

ILSCO® ClearChoice® IK-500 Type IK Split Bolt Connector, 250 to 500 kcmil, 8 AWG Compact/Compressed/Concentric/Solid Copper Conductor, 1-5/8 x 3 in, Copper Alloy

In Stock
HCI of Jackson: 0
HCI of Dyersburg: 0
HCI of Humboldt: 0
HCI of Union City: 11
HCI of Gallatin: 0
My Wishlist
Compare
Main specs
  • Brand
    ILSCO®
  • UPC
    783669470222
  • Manufacturer Part Number
    IK-500
  • Country
    USA
Specification
  • Temperature Rating
    90 deg C
  • Material
    Copper Alloy
  • Type
    Type IK
  • Conductor Size
    250 to 500 kcmil, 8 AWG
  • Conductor Type
    Compact/Compressed/Concentric/Solid Copper
  • Voltage Rating
    2000 V AC
  • Dimensions
    1.812 in H x 3 in W
  • Specifications
    0.834 in Split, 1.812 in Hex Nut, 825 in-lb Recommended Torque
  • Bolt Size
    1-5/8 x 3 in
Features
  • Manufactured from high strength copper alloy provides maximum conductivity and high breakage resistance
  • Precision tooled threads allows maximum torque to be applied
  • For use with copper conductor types solid, compact, compressed, concentric
  • Suitable for direct burial in earth and concrete
  • Application versatility
  • Allows maximum torque to be applied
Additional Information
  • Alternative Part Number
    7771265
  • UNSPSC
    39121408
  • IDEA Index ID
    7771265
  • Package Description
    EACH
  • Standards/Approvals
    CSA Certified|RUS Certified|UL 467|PROP65: Cancer and Reproductive Harm - www.P65warnings.ca.gov
