Fluke® FLUKE-77-4 Digital Multimeter, 1000 VDC/VAC, 10 A, 50 MOhm Measuring, 600 mV AC to 1000 V AC/6 to 1000 V DC, 60 mA to 10 A, 600 Ohm to 50 MOhm, Digital Display
Fluke® 77 IV digital multi-meter has the features needed to repair most electrical and electronic problems. This meter is simple to use and has significant improvements over Fluke®'s original 70 series with more measurement functions, conformance to the latest safety standards and a much larger display that's easier to view.
-
BrandFluke®
-
UPC095969365239
-
Manufacturer Part NumberFLUKE-77-4
-
CountryUSA
-
Capacitance1 nF to 9999 uF
-
Temperature Rating-10 to 50 deg C
-
MaterialHard Plastic
-
Measuring Range1000 VDC/VAC, 10 A, 50 MOhm
-
Frequency Rating99.99 Hz to 99.99 kHz
-
Resistance600 Ohm to 50 MOhm
-
Accuracy+/- (2% + 2) for AC Voltage, +/- (0.3% + 1) for DC Voltage
-
Voltage Rating600 mV AC to 1000 V AC/6 to 1000 V DC
-
Safety RatingCAT III 1000 V, CAT IV 600 V
-
Amperage Rating60 mA to 10 A
-
Battery Type9 VDC Alkaline, NEDA 1604/1604A V
-
Dimensions3.54 in W x 1.7 in D x 7.28 in H
-
Diode TestYes
-
Display TypeDigital
- Large display that makes easier to view
- Ergonomic over-molded housing with integrated probe holders
- Min/max to record signal fluctuations
- Backlight for work in dim areas
- Free your hands with the optional TPAK magnetic hanger
- Auto and manual ranging
- ANSI/ISA S82.02.01, CSA C22.21010.1, IEC 61010 to 1000 VAC measurement category III, 600 VAC measurement category IV
- Resistance range - 600 Ohm, 6 kOhm, 60 kOhm, 600 kOhm, 6 MOhm, 50 MOhm with accuracy of +/-(0.5% + 1)
- Capacitance range 1 nF, 10 uF, 100 uF with accuracy of +/-(1.2% + 2), 9999 uF with accuracy of 10%
- Frequency range 99.99 Hz, 999.9 Hz, 9.999 kHz, 99.99 kHz with accuracy of +/-(0.1% + 1)
- 400 hours typical alkaline
- Digital 6000 count, update 4/s, bar graph 33 segments display
| Competitor Name | Competitor Part Number |
|---|---|
| Grainger | 1TFV1 |
| Grainger | 1TFV1 |
-
Alternative Part Number2727486|9652316
-
UNSPSC41113630
-
IDEA Index ID9652316
-
Standards/ApprovalsANSI/ISA S82.02.01|CSA C22.2 No. 1010.1|ECCN 3A992|IEC 61010|TUV (EN 61010)/(N10140) Approved|UL Listed|VDE Certified
-
Specification Sheet
