JA-2200 -inch bore, 2-bolt base mounted spherical roller bearing pillow block manufactured by the Jones Bearing Company.
• Shaft Bore Diameter: 2 inches
• Housing Type: JA-2000 Series 2-Bolt Pillow Block
• Bearing Insert: Double-row self-aligning spherical roller bearing
• Unit Weight: 11.6 lbs
• Housing Dimensions:
• Total Length (A): 8-3/8 inches
• Bolt Hole Spacing (B): Min 5-15/16 inches to Max 6-9/16 inches
• Footprint Width (C): 1-3/16 inches
• Base to Center Height (D): 2-1/4 inches
• Total Height (E): 4-5/8 inches
• Bolt Diameter: Accommodates 5/8 inch mounting hardware
