TC-1423 7/8"-ID Needle an inch-series axial needle roller and cage thrust bearing assembly.
AI Mode Conversation: ina hk15162rs
ina hk15162rs
The INA HK1516-2RS (often appended with the standard factory grease suffix L271) is a premium drawn cup needle roller bearing featuring integrated lip seals on both sides. Manufactured by the Schaeffler Group under the INA brand, this open-ended, single-row bearing is designed to support high radial loads within an exceptionally compact footprint.
Technical Specifications
The precise engineering dimensions and performance thresholds for this specific model include:
Metric Feature Specification Value
Under-Roller Bore Diameter (\(F_{w}\)) 15 mm
Outside Diameter (D) 21 mm
Width (C / B) 16 mm
Basic Dynamic Load Rating (\(C_{r}\)) 7,800 N
Basic Static Load Rating (\(C_{0r}\)) 9,800 N
Limiting Speed (Grease) 9,900 rpm
Net Weight ~14 grams
Key Identification Codes
• HK: Drawn cup needle roller bearing with open ends.
• 1516: Identifies the primary dimensions (15 mm internal diameter under rollers, 16 mm width).
• -2RS: Equipped with contact lip seals on both sides to retain grease and protect against contaminants.
• -L271: Standard factory designation for the specific initial grease fill optimized for standard operating ranges.
Procurement Options
The individual bearing or multipacks can be ordered through online industrial distributors:
INA Schaeffler HK15162RSL271 (Single)
$6.49
RS - America
Available individual units in stock at RS - America.
INA HK1516-2RS-L271 (8-Pack)
$62.98
PLC Source
5.0 ★ (1)
Bulk option for component replenishment via PLC Source.
Premium HK1516-2RS-L271
$4.98
cmt.gmbh
5.0 ★ (1)
International shipping options provided directly by cmt.gmbh.
Are you searching for an exact interchange/cross-reference from another brand (like SKF or Koyo), or do you need help verifying the shaft tolerances required for mounting this bearing?
Try without personalization
•
Schaeffler Group USA Inc.
HK1516
Drawn cup needle roller bearings with open ends HK..
