Appleton® ETP™ WFC2050G Weatherproof Floodlight Fixture With Guard, (1) Incandescent Lamp, 120 V AC, Polyester Powder Coated Housing
Appleton® ETP™ WFC2050G Weatherproof Floodlight Fixture With Guard, (1) Incandescent Lamp, 120 VAC, Polyester Powder Coated Housing
-
BrandAppleton®
-
UPC687855031252
-
Manufacturer Part NumberWFC2050G
-
CountryUSA
-
TypeWeatherproof
-
Mounting TypeCeiling
-
Voltage Rating120 V AC
-
Housing MaterialDie Cast Aluminum
-
Number of Lamps1
-
Dimensions10.75 in H x 5.33 in W
-
Lamp Base TypeMedium
-
Lamp TypeIncandescent
-
Lamp Wattage200 W
-
Lens TypeAnnealed Glass
- Rugged continuous and seamless die-cast construction prevents entry of dirt, dust and moisture
- Polyester powder coating is applied for uniform cosmetic coating and weatherproof durability
- Mounting can be achieved with mounting lugs (provided) or by using the integral mounting knockouts
- Smooth, accurately tapped hubs prevent wire abrasion
- Locking swivel knuckle on lamp holders permits positive lamp positioning and accurate directional aiming
- Factory assembled and fully gasketed to ensure fast and easy installation
- Lighting fixtures are individually boxed, labeled and bar coded for ease of handling and identification
- Complete installation instructions are provided with each item
- Use with 125 deg C (257 deg F) supply wire
-
Alternative Part Number8987747
-
UNSPSC39111611
-
IDEA Index ID8987747
-
Package DescriptionEACH
-
Standards/ApprovalsCSA C22.2 250 Certified|UL 15998 Listed
-
Specification Sheet
