Enerpac® ZU4308SB Pro Universal Z-Class Electric Hydraulic Pump, 1.7 hp, 2 gal Reservoir, 60 cu-in/min Flow Rate, 10000 psi Pressure
Enerpac® ZU4308SB Pro Universal Z-Class Electric Hydraulic Pump, 1.7 hp, 2 gal Reservoir, 60 cu-in/min Flow Rate, 10000 psi Pressure
-
BrandEnerpac®
-
UPC662005127399
-
Manufacturer Part NumberZU4308SB
-
CountryUSA
-
Pressure Port3/8 in NPT
-
Pressure Rating10000 psi
-
Flow Rate60 cu-in/min
-
Frequency Rating50/60 Hz
-
Reservoir Capacity2 gal
-
TypeUniversal Z-Class
-
Voltage Rating115 V
-
SeriesPro ZU Series
-
Horsepower1.7 hp
-
Overall Height16.7 in
-
Overall Length25 in
-
Overall Width10-1/2 in
- Patented Z-Class pump technology provides high bypass pressures for increased productivity, important in applications using long hose runs and high pressure drop circuits, like heavy lifting or certain double acting tools
- Enerpac® ZU4 hydraulic pumps are built to power small to large sized cylinders or hydraulic tools or wherever high speed, intermittent duty, remote hydraulic power is needed
- Features Z-Class high efficiency pump design, higher oil flow and bypass pressure, cooler running and requires 18% less current draw than comparable pumps
- Powerful 1.7 hp universal electric motor provides high power to weight ratio and excellent low voltage operating characteristics
- High strength, molded composite shroud protects motor and electronics, while providing an ergonomic, non-conductive handle for easy transport
- Low voltage pendant provides additional safety for the operator
- LCD readout provides pressure and a number of diagnostic and readout capabilities never before offered on a portable electric pump
- Pump usage information, hour and cycle counts
- Self-test, diagnostic and readout capabilities
- Pressure readout and auto mode pressure settings
-
UNSPSC40151533
-
Standards/ApprovalscTUVus Certified
-
WarrantyLimited
-
