Diversitech 108-130220 Variable Motor Start Capacitor, 108 to 130 uF, 220/250 V AC, Round
This DiversiTech® 108-130220 Motor Start Capacitor, 108-130µF, 220/250 volts motor start, electrolytic, non-polarized capacitor is designed for normal intermittent service on single-phase A/C motor starting circuits. Motor Start Capacitor lets the motor turn on and off rapidly, and helps the motor run more efficiently.
-
BrandDiversitech
-
UPC095247070602
-
Manufacturer Part Number108-130220
-
CountryUSA
-
Capacitance108 to 130 uF
-
Case MaterialPlastic
-
ColorBlack
-
TypeVariable
-
Voltage Rating220/250 V AC
-
ShapeRound
-
Dimensions1.812 in Dia x 3.37 in H
-
Domestic/ImportDomestic
-
Specifications50/60 Hz
- Features a round, molded case that protects it from oil, dirt, moisture, and grease
- Motor start capacitor lets the motor turn on and off rapidly, and helps the motor run more efficiently
- Permissible temperature range of -40C to +65C
-
UNSPSC32121500
-
Package DescriptionEACH
-
Standards/ApprovalsUL Listed
-
Warranty1 year
-
Specification Sheet
