GREY PNEUMATIC 1-1/8" 8-PT DEEP 3/4"-DR I/SOCKETS GRY 3536-SD
GP® 3536SD Deep Length Shape III Socket, 3/4 in Double Square Drive, 1-1/8 in, 8 Points
-
BrandGP®
-
UPC729440474249
-
Manufacturer Part Number3536SD
-
CountryUSA
-
MaterialAlloy Steel
-
Measurement SystemImperial
-
TypeDeep Length Shape III
-
Impact RatedYes
-
Number of Points8
-
Socket End Width2.2 in
-
Socket Size1-1/8 in
-
Opening Depth3/4 in
-
Drive End Width1-3/4 in
-
Drive Size3/4 in
-
Drive TypeSquare
-
Bolt Clearance Depth2.68 in
-
Overall Length3.74 in
- Increased strength transfers the pressure from the thinnest part of the socket wall toward the thicker section, resulting in increased strength
- Increased torque allows up-to 20% more torque to be applied than on standard hex impact sockets
- Easier access to tight areas the shift in pressure allows usto reduce the socket wall thickness, increasing access to tight areas
- Reduced wear and grip the fastener across abroader contact area, reducing the chance of rounding off fasteners
-
UNSPSC27112828
-
WarrantyLifetime
-
