Proto Tools 50-MM 12-PT 3/4"-DR SOCKET PRO J-5550-M
Proto® TorquePlus™ J5550M Standard Length Socket, Metric, 3/4 in Square Drive, 50 mm
-
BrandProto®
-
UPC662679200435
-
Manufacturer Part NumberJ5550M
-
CountryUSA|Canada
-
Locking TypeBall
-
FinishSatin
-
MaterialAlloy Steel
-
Measurement SystemMetric
-
TypeStandard Length
-
Number of Points12
-
Socket End Width70.1 mm
-
Socket Size50 mm
-
Opening Depth44.2 mm
-
Drive End Width51.6 mm
-
Drive Size3/4 in
-
Drive TypeSquare
-
Bolt Clearance Depth44.2 mm
-
Overall Length80.2 mm
- The TorquePlus™ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners
- The TorquePlus™ configuration employs a radius corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage
- The TorquePlus™ internal design minimizes fastener rounding, helps to extend fastener life and allows the user to more easily turn worn, rounded or rusted fasteners
- Ball detent design
| Competitor Name | Cross-Reference Number |
|---|---|
| Grainger | 429T27 |
-
UNSPSC27111704
-
Package DescriptionEACH
-
Standards/ApprovalsASME B107.110-2012
-
