Browning 21-TOOTH 6-PITCH BEVEL GEARS BRW YS-B-6-B-21-20
Browning® 1228378 MPB Straight Tooth Bevel Pinion Gear, 6 Diametral Pitch, 20 deg Pressure Angle, 21 Teeth, 3-1/2 in Dia Pitch, 1.05 in W Face, 1 to 1-5/8 in Dia Bore, Steel
-
BrandBrowning®
-
UPC662289185030
-
Manufacturer Part Number1228378
-
CountryUSA
-
Face Width1.05 in
-
Pitch Diameter3-1/2 in
-
MaterialSteel
-
Pressure Angle20 deg
-
Gear Ratio2:1
-
TypeMPB Straight Tooth
-
Hub Diameter2-1/2 in
-
Hub Projection1-1/4 in
-
Diametral Pitch6
-
Number of Teeth21
-
Bore Diameter1 to 1-5/8 in
-
Overall Length2-33/64 in
- Browning Gears are rated in accordance with AGMA standards
- Mating Spur Gears must have same pressure angle and pitch
- Modification Options Available - 1. Cut to Desired Length, 2. Milled and Matched Ends, 3. Drilled or Drilled and Tapped Holes for Mounting
-
Alternative Part NumberYSB6B21-20
-
UNSPSC31171708
-
Package DescriptionEACH
-
Standards/ApprovalsAGMA Standard
-
Warranty1 Year
-
