Edison S506-3.15-R Low Breaking Time Delay Fuse With Nickel Plated Brass End Caps, 3.15 A, 250 V AC, 35 A, Cylindrical Body
Edison S506-3.15-R Low Breaking Time Delay Fuse With Nickel Plated Brass End Caps, 3.15 A, 250 VAC, 35 A, Cylindrical Body
-
BrandEdison
-
UPC051712639767
-
Manufacturer Part NumberS506-3.15-R
-
CountryUSA
-
Terminal TypeFerrule
-
MaterialGlass
-
Frequency Rating50 Hz
-
Rejection/Non-RejectionNon-Rejection
-
TypeLow Breaking
-
Mounting TypeHolder
-
Voltage Rating250 V AC
-
Amperage Rating3.15 A
-
SeriesS506
-
Indicating/Non-IndicatingNon-Indicating
-
Interrupt Rating35 A
-
Body Size5.2 mm Dia x 20 mm L
-
Body TypeCylindrical
-
ElementSingle
- 35 A at 250 VAC interrupt rating
-
UNSPSC39121609
-
IDEA Index ID9527053
-
Package DescriptionEACH
-
Standards/ApprovalsRoHS Compliant|UL File No. E19180, Guide JDYX2|CSA Component Acceptance File No. 1803366|cURus Guide JDYX8|UL File No. E19180|SEMKO File 507078, 415434, 806492|VDE 40011926|BSI KM55676|IMQ E1921|CA03.00530|PSE/JET File JET1641-31003-1005|PSE/JET File JET1641-31003-1006|CCC File 2005010207155693/2002010207011294
-
