Morse® 131148 MHSTK Hole Saw, 7/8 in Dia, 1-15/16 in D Cutting, Carbide Cutting Edge, 1/2 to 20 Arbor
Morse® 131148 MHSTK Hole Saw, 7/8 in Dia, 1-15/16 in D Cutting, Carbide Cutting Edge, 1/2 to 20 Arbor
-
BrandMorse®
-
UPC050326131148
-
Manufacturer Part Number131148
-
CountryUSA|Canada
-
Chuck Size1/4 in
-
Use ArborMA34CT
-
Applicable MaterialsFiberglass/Plastic/Composites/Aluminum/Carbon Steel/Computer Flooring/Fastener Embedded Wood/Stainless Steel/Tile Backer
-
Arbor Size1/2 to 20
-
SeriesMHSTK
-
Cutting Depth1-15/16 in
-
Shank Size3/8 in
-
Cutting Edge MaterialCarbide
-
Cutting Edge StyleToothed
-
Shank TypeHex
-
Diameter7/8 in
-
Speed195 to 585 rpm
-
Drill Size1/4 in Dia x 3-3/32 in L
-
Body MaterialSteel
-
TPI or Pitch3 TPI
- Patented carbide tooth design for better chip clearance
- Ground set pattern
- Smoother entry for better control and cleaner cut finish
- Tungsten carbide tooth tips offer the highest wear resistance possible for fast holes and longer life cutting abrasive materials
- Arbor required
| Competitor Name | Cross-Reference Number |
|---|---|
| Berkshire eSupply | FZ50157148 |
-
Alternative Part NumberMHSTK14
-
UNSPSC27112826
-
Package DescriptionEACH
-
WarrantyLimited
-
