Browning GRIDFLEX P-BUSH COUPLING HALFS BRW 1060-HUB X P
Kop-Flex® Kop-Grid® 2274611 Split-Taper® Bushed Coupling Hub, 1060, 1-3/4 in Dia Bore, 2-1/2 in Length Through Bore, 3 in Dia Hub, Carbon Steel
-
BrandKop-Flex®
-
UPC662384102352
-
Manufacturer Part Number2274611
-
CountryUSA
-
MaterialCarbon Steel
-
Maximum Speed4350/6000 rpm
-
TypeSplit-Taper® Bushed
-
Coupling Size1060
-
Hub Diameter3 in
-
Hub Length2-1/2 in
-
Length Through Bore2-1/2 in
-
Bore Diameter1-3/4 in
- Provide torsional damping to reduce torsional vibration and cushion shock loads
- Grids act much like a protective overload shear device during overloads to protect expensive, connected equipment
- Quick and easy installation with low maintenance
- Uses P1 bushing
-
Alternative Part Number1060 HUBXP
-
UNSPSC31163012
-
Package DescriptionEACH
-
Warranty1 Year
-
Specification Sheet
