Koyo B-2212 Inch Series Open Ends Uncaged Drawn Cup Needle Roller Bearing, 1-3/8 in Dia Bore, 1-5/8 in OD, 3/4 in W, 6830 lbf Dynamic/16000 lbf Static Load
Drawn cup needle roller bearings support radial loads and reduce friction between rotating components, with a drawn outer shell serving as a raceway for the rollers. The small cross section of the drawn cup bearing provides high load-carrying capability with minimum required space. Drawn cup bearings are easily installed with a press fit in the housing.
-
BrandKoyo
-
UPC605790184857
-
Manufacturer Part NumberB-2212
-
CountryUSA
-
Load Capacity6830 lbf Dynamic/16000 lbf Static
-
Temperature Rating250 deg F
-
Maximum Speed3200 rpm
-
Closure TypeOpen
-
TypeOpen Ends Uncaged
-
Width3/4 in
-
SeriesB Inch Series
-
Outside Diameter1-5/8 in
-
Bore Diameter1-3/8 in
- Full complement bearings handle high radial load-carrying capability
| Competitor Name | Cross-Reference Number |
|---|---|
| Grainger | 779K49 |
-
Alternative Part NumberB2212PBL125
-
UNSPSC31171505
-
Standards/ApprovalsANSI/ABMA 18.2
-
