FED/Bronze 1/2" X 13" SOLID BRONZE BARS FEB 1/2 X 13
ISOSTATIC™ Century® 106501 Solid Bar, 1/2 in OD, 13 in OAL, SAE 660 Cast Bronze
-
BrandISOSTATIC™
-
UPC846802026257
-
Manufacturer Part Number106501
-
CountryUSA
-
Temperature Rating-450 to 450 deg F
-
MaterialSAE 660 Cast Bronze
-
Diameter1/2 in OD
-
Overall Length13 in
- Standard stock products
- SAE 660/CA 932 copper 83%, tin 7%, lead 7% and zinc 3%
- Non-porous, highly dense grain structure for long life
- Offers good hardness, strength and wear resistance, excellent anti-frictional characteristics
- Tensile strength of 35000 psi, yield strength of 27000 psi and brinell hardness of 72
- Ideal for heavy loads at moderate speeds or light loads at high speeds
- Products made with excess material to finish to stated nominal dimensions
-
Alternative Part NumberBS0004-13
-
UNSPSC31171500
-
Package Description1/PK
-
Standards/ApprovalsASTM B505|QOC-390B Type III B144-52-3B|REACH Compliant|PROP65: This product can expose you to chemicals including lead which is known to the state of California to cause birth defects or other reproductive harm. For more information go to www.P65WARNINGS.ca.gov
-
Specification Sheet
-
Catalog
