Link-Belt® 10443110 200 Intermediate Duty Pillow Block Ball Bearing Unit, 1-7/16 in Dia Bore, 3-1/4 in L Bolt Center-to-Center, 1-7/8 in Base to Bore Centerline, 4-13/32 in OAL x 3-11/16 in OAH
200 series intermediate duty ball bearing units provide a versatility of application arrangements for carrying shafts with radial or combination radial and thrust loads. They are designed for general purpose industrial machinery, conveyors, chain and belt drives, fans and blowers, power transmission and many other applications.
-
BrandLink-Belt®
-
UPC662864724821
-
Manufacturer Part Number10443110
-
CountryUSA|Canada
-
Load Capacity5810 lb Dynamic/3440 lb Static
-
Locking DeviceSet Screw
-
Temperature Rating-40 to 275 deg F
-
FinishPowder Coated
-
MaterialCast Iron
-
Maximum Speed4800 rpm
-
TypeIntermediate Duty
-
Mounting TypeTapped Base
-
Seal TypeSingle Lip
-
Series200
-
Base Width2 in
-
Base to Bore Centerline1-7/8 in
-
Bolt Center-to-Center Length3-1/4 in
-
Bore Diameter1-7/16 in
-
Bore TypeRound
-
Overall Height3-11/16 in
-
Overall Length4-13/32 in
-
Overall Width1-9/16 in
- Alignable precision deep groove ball bearing manufactured of quality alloy bearing steel provides high capacity and long life
- Compact 1-piece housing provides excellent mounting support
- Integral bearing seals
- Narrow inner ring
- Relubricatable bearing
- FKM seal material
- High temperature grease
- 207 size code
-
Alternative Part NumberPT3S223E14C
-
UNSPSC31171500
-
Standards/ApprovalsANSI|ABMA STD 9
-
Warranty1 Year
-
Package DescriptionEACH
-
Catalog
-
Instruction/Installation Manual
