F4R-IP-215R Dodge® 069611 215 Imperial Non-Expansion Round Flange Mount Bearing, 2-15/16 in Dia Bore, 3.81 in L Bolt Center-to-Center, 7.88 in Dia Bolt Circle, 4-Bolt Flange Mount, 9-1/4 in OAL/Dia
Dodge® spherical bearings, including imperial bearings, are general purpose, high capacity, double row spherical roller bearings. All imperial bearings are mounted in 1-piece, precision machined housings. Bearings are mounted to shafts by means of a patented adapter system that improves concentricity and reduces inherent vibration. ASTM A48 Class 30 cast iron is the standard material used in imperial housings. Housing designs are available for survival in extremely harsh environments, through the use of special finishes and stainless hardware. Housings are available in a variety of standard configurations, including pillow blocks, flanges, piloted flanges and take-up bearings. Trident triple lip contact seals and labyrinth seals are available on imperial bearings.
-
BrandDodge®
-
UPC782475309078
-
Manufacturer Part Number069611
-
CountryUSA
-
Load Capacity41500 lb Dynamic/53000 lb Static
-
Locking DeviceTapered Adapter Sleeve
-
Temperature Rating-100 to 250 deg F
-
FinishUncoated
-
Flange Mounting Type4-Bolt
-
Maximum Speed2250 rpm
-
TypeImperial Non-Expansion Round
-
Series215
-
Bearing MaterialCast Iron
-
Bolt Center-to-Center Length3.81 in
-
Bolt Circle Diameter7.88 in
-
Bore Diameter2-15/16 in
-
Overall Depth3.81 in
-
Overall Length/Diameter9-1/4 in
- Steel cage with guide rings offers precision roller guidance
- Adapter sleeve improves concentricity and reduces inherent vibration
- Ease in mounting and dismounting achieved through patented adapter system
- Push-pull adapter mount
- Grease limiting speeds 30% higher than setscrew mounts
- All housings are class 30 gray iron
- Shaft ready installation
- Superior holding power reduces the fretting corrosion caused by vibration
- Seal/land on OD of inner ring maintains full contact pressure even when misaligned
- Less shaft damage vs setscrew mounts
- Reduced vibration damage vs setscrew mounts
-
Alternative Part NumberF4R-IP-215R
-
UNSPSC31171510
-
Package DescriptionEACH
-
Standards/ApprovalsARRA Compliant|Buy American Act Compliant|RoHS Compliant|UL Listed|AGMA|MPTA|ABMA|BSA|PTDA|CMA|HI
-
