FYH® ALF206 20FP9 ALF Cylindrical Flange Mount Ball Bearing Unit, 1-1/4 in Dia Bore, 3-9/16 in L Bolt Center-to-Center, 15/32 in Dia Bolt Circle, 2-Bolt Flange Flange Mount, 4-7/16 in OAL/Dia
FYH® ALF206 20FP9 ALF Cylindrical Flange Mount Ball Bearing Unit, 1-1/4 in Dia Bore, 3-9/16 in L Bolt Center-to-Center, 15/32 in Dia Bolt Circle, 2-Bolt Flange Flange Mount, 4-7/16 in OAL/Dia
-
BrandFYH®
-
Manufacturer Part NumberALF206 20FP9
-
CountryUSA
-
Load Capacity19.5 kN Dynamic/11.3 kN Static
-
Locking DeviceEccentric Locking Collar
-
Flange Mounting Type2-Bolt Flange
-
TypeCylindrical
-
SeriesALF
-
Bolt Center-to-Center Length3-9/16 in
-
Bolt Circle Diameter15/32 in
-
Bore Diameter1-1/4 in
-
Overall Depth1-1/2 in
-
Overall Height3 in
-
Overall Length/Diameter4-7/16 in
