Smith Bearing® HR-3/4-XB Cylindrical Stud Type Needle Bearing Cam Follower, 3/4 in Dia x 1/2 in W Roller, 7/16 in Dia x 7/8 in L Stud, 52100 Steel Roller
The HR Series have a larger diameter stud and are recommended for applications with high running loads and/or heavy shocks where deflection should be held to a minimum. Rollers and outer races are identical to the standard CR Series. Manufactured from high alloy bearing quality steel.
-
BrandSmith Bearing®
-
UPC651041136014
-
Manufacturer Part NumberHR-3/4-XB
-
CountryUSA
-
Load Capacity2140 lb Dynamic/4150 lb Static
-
Thread Length3/8 in
-
Thread Size7/16-20 UNF-2A
-
Closure TypeSealed
-
TypeCylindrical Stud Type
-
Roller Diameter3/4 in
-
Roller Material52100 Steel
-
Roller Width1/2 in
-
Head TypeHex Socket
-
SeriesHR-XB
-
Stud Diameter7/16 in
-
Stud Length7/8 in
-
Stud TypeHeavy
| Competitor Name | Competitor Part Number |
|---|---|
| Grainger | 11Y048 |
-
UNSPSC31171530
-
Warranty12 months
-
