Bosch DS150I PIR Detector, 12/24 VAC/VDC
Bosch DS150I PIR Detector, 12/24 VAC/VDC
-
BrandBosch
-
Manufacturer Part NumberDS150I
-
CountryUSA
-
Temperature Rating-20 to 120 deg F
-
MaterialHigh Impact ABS
-
Power Source12/24 VAC/VDC
-
ColorLight Gray
-
Specifications26 mA at 12 VDC
- The DS150i detect motion in their coverage area and signal an access control system or door control device
- Externally visible activation LED
- Single or double door use
- Wall or ceiling mountable
- Internal vertical pointability
- Wrap-around coverage pattern
- Selectable relay trigger mode
- Provides PIR, 2.4 m x 3 m (8 ft x 10 ft) coverage
- Two form C relay contacts alarm output
- Adjustable to 60 sec relay latch
- 1-1/2 x 6-1/4 x 1-1/2 in enclosure
- Programmable fail-safe or fail-secure modes
- Programmable reset (accumulative) or non-reset (counting) mode
- No alarm or setup on critical frequencies in the range from 26 MHz to 1000 MHz at 50 V/m
-
UNSPSC32101519
-
Specification Sheet
